Ultra-Slim, Undecoded 2D Imager, SR (Standard Range) and HD (High Density) Optics, Advanced Laser and LED Aimers The N670X Series 2D barcode scan engine is Honeywell's slimmest 2D imager. It is designed to provide higher performance and reliability, simplify integration into mobile devices, and enable increased barcode scanning speeds to meet higher-volume application requirements. Parallel or MIPI interface availability helps simplify integration into mobile devices that require the most current, as well as traditional, processor interfaces. Its compact dimensions (6,8 mm [0.27 in] height x 16,2 mm [0.64 in] depth) free up more room for other technology integration. Read range and readability have been leveled up in the N670X Series. Based on a 1 Mpx global shutter sensor, it can read Code 39 20 mils at 0,8 m [31.5 in] distance (SR optics typical read range) and provides an increased read range by 40% compared to its predecessor. Its white LED illumination enhances image capture accuracy while the HD optics allow reading of higher resolution codes (down to 2.5 mils on Code 39 1D barcodes and down to 5 mils Data Matrix and QR barcodes). Equipped with its HD Optics, the N670X can read the new DotCode for tobacco products traceability down to a resolution of 5 mils. With notable maximum motion tolerance of 6 m/s [236 in/s], the N670X Series can read moving barcodes, enabling increased scanning speed and productivity. The choice of high brightness LED (2X brighter than the current system) and laser aiming systems provides the flexibility to better suit customer application requirements and environments while further improving the aimer visibility for the users. The lower typical power consumption (210 mA at 3.6 V, maximum) increases the battery life provided by a single charge. This product is electrically backward-compatible with Honeywell's N660X Series and N360X Series, which all use the same connector, reducing integration time and design costs while increasing design flexibility and choice. All three scan engine families are considerably slim and can fit in compact enclosures, enabling you to offer two different levels of barcode scanning performance to your customers without a housing change or additional accessory design. The N670X can help the enterprise mobility, tablet, sled and wearable device maker lead the way in offering products that may exceed general industry standards pertaining to scanning performance, reliability and integration flexibility. Built on Honeywell's latest decoding and imaging technology, this product is backed up by a savvy engineering team readily available to offer you support for your integration needs. Features At 6,8 mm, the slim height makes it easier to fit today's and tomorrow's compact devices. Wider operational temperature range increases potential applications. Available with two optics: SR optics read UPC codes up to 573 mm (22.5 in), and HD optics enable reading of DotCode, 2,5 mil C39, and 5 mil Data Matrix high resolution codes. Delivers motion tolerance of up to 6 m/s, enabling operational effectiveness. Lower power consumption increases battery life. Compatible with Honeywell's N660X Series and N360X Series for reduced integration time and increased design flexibility. Parallel or MIPI interface availability helps simplify integration. Choice of high brightness LED and laser aiming systems to better suit application requirements while improving aimer visibility. Supports Honeywell optional functionalities such as OCR, Easy Parse for driving licenses, boarding passes or automotive parts. Potential Applications Designed for use in professional-grade, mobile devices such as tablets, wearable scanners, mobile terminals, accessories in retail stores, warehouses, and healthcare facilities, as well as delivery, pick-up/drop-off, and field servicing. Contactless technology and automation are transforming the way we live and work. Honeywell Logistics Sensing is developing the latest vision solutions to support a wide range of applications for: access control, retail, healthcare, transportation and logistics, warehouse and distribution, and hospitality. Specifications OTHERS Industry Retail
If you were to look inside the ultra-compact N660X Series engine, you'd find a proprietary imaging sensor designed specifically for professional barcode reading. With its powerful white illumination, this compact sensor captures more detail. It's exceptionally motion tolerant, too, so it can decode hard-to-read barcodes and tolerate challenging ambient light environments with ease. The N660X Series also puts a premium on interface flexibility. These products support both traditional parallel and MIPI interfaces for emerging technologies. This enables easier integration with the latest processors, saves space, reduces overall design cost and shortens the integration and development cycle. The N660X Series is backwards compatible with nearly all N560X Series designs, which reduces development complexity and makes it easier and faster to integrate. They also provide a choice of better visibility LED or laser aimers to give flexibility to better suit customer application requirements. As one of our next-generation flagship products, the N660X series inherits the most advanced imaging technology from both Honeywell and legacy Intermec. It's also a smart choice for enterprise mobility, tablet, sled and wearable device makers who don't want to compromise thermal management, power consumption, peak current control and EMI for unmatched 2D scanning performance. Features Ultra compact: At only 6,8 mm, the slim height makes it easier to fit today's and tomorrow's ultra slim devices. MIPI interface available: Supports the latest technology trends for shorter design cycles. White illumination: Choice of LED or laser aiming systems. Enhanced flexibility: Supports customers' electronic design. Enhanced performance: Delivers improved scan speed, motion tolerance up to 5,8 m/s, enhanced reading capability for poorly printed barcodes, support for color barcodes, and full symbology support. Contactless technology and automation are transforming the way we live and work. Honeywell Logistics Sensing is developing the latest vision solutions to support a wide range of applications for: access control, retail, healthcare, transportation and logistics, warehouse and distribution, and hospitality. Specifications FEATURES Aimer Type Laser Symbol Contrast 20% Minimum Reflectance Features & Benefits At Only 6.8 mm the Slim Height Makes it Easier to Fit Today's and Tomorrow's Ultra Slim Devices Choice of Better Visible LED or Laser Aimers Gives Flexibility to Better Suit Customer Application Requirements Delivers Improved Scan Speed Motion Tolerance Up To 5 M/S Enhanced Reading Capability for Poorly Printed Barcodes Optimized White Illumination Enhances Barcode Reading Performance Support for Color Barcodes and Full Symbology Support Supports the Latest Technology Trends for Shorter Design Cycles Ambient Light Immunity 0 to 100,000 lux ELECTRICAL SPECIFICATIONS Working Current 315 Input Voltage 3.3 VDC ±5% Idle Current 150 OVERVIEW Warranty 15 Month Limited Warranty (The Warranty Period Starts at Date of Shipment From Honeywell to Customer) Brand Honeywell OPERATING CHARACTERISTICS Storage Temperature-40 to 85°C Humidity 0 to 95% RH (Non-Condensing at 50°C) STANDARDS & CERTIFICATIONS Standards & Approvals 21CFR 1040.10 21CFR 1040.11 IEC 60825-1:2007 IEC 60825-1:2014 TECHNICAL SPECIFICATIONS Sensor Type Proprietary CMOS Sensor With Global Shutter and 844 × 640 pixel Resolution; 60 Frames Per Second Max Scan Angle (°) 360°, pitch: ±45°, skew: ±60° Motion Tolerance Up to 584 cm [230 in] per second in Total Darkness with 100% UPC at 10 cm [4 in] Distance Illumination White LED (Exempt Risk Group) Host Interface MIPI Parallel Field of View Extended Range (ER): 35.6° (H) x 27.5°C (V) Standard Range (SR): 42.4° (H) x 33°C (V) DIMENSIONS & WEIGHT Dimension L: 23.5 mm W: 16.2 mm H: 6.8 mm OTHERS Industry Retail.
The N360X Series 2D barcode scan engine is a very compact, undecoded 2D imager designed for use in mobile devices. The N360X Series inherits Honeywell's long history of successful decoding experience and hardware performance to provide an easier-to-integrate, enhanced performance device that fits into tight mobile device designs. Parallel or MIPI interface availability helps simplify integration into mobile devices that require the most current, as well as traditional, processor interfaces. The dimensions (8,1 mm [0.32 in] height x 10,8 mm [0.43 in] depth) are some of the most compact in its class. The reduced footprint frees up room for other technology integration. The N360X Series does not compromise on performance. Based on a 1 Mpx rolling shutter sensor, the N360X Series increases its read range by 80% versus traditional VGA sensor-based imagers and can read EAN 100% at 541 mm [21.3 in] distance (typical read range). Its new sensor enables the reading of higher resolution codes (down to 3 mils on Code 39 1D barcode) and the white LED illumination system enhances image capture results and readability of colored barcodes. The N360X Series is equipped with either a high definition green LED dot aimer (N3601), adapted for customer facing and healthcare applications, or a thin, bright laser aiming system (N3603) that enables reading multiple barcodes close to each other and is more visible in low light or bright light environments. The wide operational temperature range (-20°C to 50°C [-4°F to 122°F]) allows expansion into more demanding applications and the lower power consumption (152 mA to 170 mA at 3.3 V, typical) increases the battery life provided by a single charge. This product is compatible with Honeywell's N660X Series and N670X High Performance 2D Imager and uses the same connector as these two scan engine families, reducing integration time and design costs while increasing design flexibility and choice. The N670X is even slimmer than the N360X Series and both can fit in compact enclosures. This means that you may offer two different levels of barcode scanning performance to your customers without a housing change or additional accessory design. Features Parallel or MIPI interface availability helps simplify integration. Compact size allows use in tight mobile device designs. Higher performance includes increased read range and higher resolution readability. White LED enhances image capture and colored barcode readability. Choice of high definition LED or laser aiming system to match your application requirements. Wider operational temperature range increases potential applications. Lower power consumption increases battery life. Compatible with other Honeywell scan engine families for reduced integration time and design costs, as well as increased design flexibility and choice. Supports optional Honeywell functionalities such as OCR and EasyParse for potential use with driving licences and boarding passes. Potential Applications Designed for use in professional-grade, mobile devices such as tablets, wearable scanners, mobile terminals, accessories in retail stores, warehouses, and healthcare facilities, as well as delivery, pick-up/drop-off, and field servicing. Contactless technology and automation are transforming the way we live and work. Honeywell Logistics Sensing is developing the latest vision solutions to support a wide range of applications for: access control, retail, healthcare, transportation and logistics, warehouse and distribution, and hospitality. Specifications OTHERS Industry Retail
The FlexRange™ ULR is designed for ultra-long read range applications, making it ideal for warehouse environments. Despite its robust capabilities, it is packaged in a slim form factor. The newly developed Smart Adaptus™ 9.0 auto-focus and illumination design extends the read range, particularly for regular-sized codes and in sub-optimal lighting conditions. Additionally, the green laser aimer helps users locate barcodes more quickly, as the color is seven times more visible to the human eye. This scan engine effectively meets the demands of various workflows in modern warehouse applications. The FlexRange™ ULR 2D scan engines are designed to fit easily into mobile devices due to their compact size and lightweight nature. For mobile devices operating with an OS, Honeywell offers host decoder software that utilizes the device's computing capabilities. For customers creating devices without an operating system, the Gen8 DB decoder board provides a seamless barcode reading experience with minimal space requirement, making it ideal for wearable devices The FlexRange ULR 2D scan engine platform is designed to meet nearly every requirement in a warehouse environment, featuring a slim form factor with a height of just 7.6 mm [0.3 in] and light weight, ideal for mobile devices integrations. •Compact and Ergonomic Design: A height of 7.6 mm and weight of 4 g, ideal for mobile and wearable integrations. •Robust Barcode Handling: Reliable decoding of wrinkled, colored backgrounds, or over-laminated barcodes. •Effective in Low-Light Conditions: Improves low light read range by twofolds compared to its predecessor. •Consistent Read Times: Efficiently switches from near to distant barcodes without delays, reducing user fatigue during long shifts. •Laser Aimer Visibility: The green laser aimer is more effective for targeting compared to a red aimer, enabling accurate aiming at a distance •Low Power Consumption: Specifically designed for mobile and wearable devices, ensuring that battery life lasts through an entire shift or longer.
Whether you work in a distribution center, retail, logistics, or in the field, workers need the capability of scanning near, mid, and far range distances to improve workflow efficiency and reduce fatigue. Existing long-range imaging options are available, but may not be suitable, for more compact designs. Introducing the Honeywell FlexRange™ N6803 Series which includes the N6803MR, N6803FR, and N6803LR 2D scan engines. Specifications OTHERS Industry Retail.
The Extended FlexRange™ EX30 2D Scan Engine for warehouse and distribution center operations seamlessly reads barcodes from 10 cm to 20 m [4 in to 66 ft] using the latest technology for a fast auto-focus mechanism. Warehouse and distribution center operation managers need barcode scanning solutions that can read barcodes at close distances as well as those farther away, such as package labels on shelves as high as 10 cm to 20 m [4 in to 66 ft]. The EX30 answers this key requirement by enabling a wide angle read range of 42° at close distances and up to 20 m [66 ft]. Operators reading barcodes at both near and far distances expect to switch seamlessly between both operations. The Extended FlexRange EX30 uses the latest technology for a fast auto-focus lens mechanism that provides the focus change multiple times faster than its predecessor. At this level of performance, the operator feels no latency in reading across the entire distance range, allowing an efficient and comfortable work pace. The Extended FlexRange EX30's electrical interface is fully compatible with Honeywell's N670X Series, N660X Series, and N360X Series fixed-focus, compact scan engines. This compatibility provides customers with a complete barcode scanning performance offering, ranging from better to best, that fits into the same mobile device, keeping design time and resources to a minimum. The Extended FlexRange EX30 is available with either a parallel or the MIPI interface, now commonly used with the newest generation of processors. The Extended FlexRange EX30 may easily be embedded into mobile devices running under an OS by using the resources of the device's main processor. Honeywell supports its customers with integrating decoder software into their solutions, saving the cost of ownership by eliminating hardware and also enhancing performance by using the main processor's power. The Extended FlexRange EX30 may also be powered by the new Honeywell Gen7 DB Decoder Board, allowing easy integration into non-OS devices such as drones, mobile accessories and sleds. Features Near and Extended FlexRange read ranges of 10 cm to20 m [4 in to 66 ft] allow both near and far barcode reading in the same device. MIPI interface provides compatibility with newer processors. Patented, embedded, auto-focus lens mechanism enables fast, aim-and-scan operation, allowing job efficiency. Compact dimensions of 13 mm x 30,5 mm x 22,2 mm [5.12 in x 1.2 in x 0.87 in] allow easier fit into slimmer mobile device designs. Fully compatible with Honeywell’s N670X, N660X, and N360X Series scan engines, reduces integration time and increases design flexibility. Flexible choice of decoder software or hardware (Honeywell Gen7 DB Decoder Board) options allow integration into both OS and non-OS supported devices. Potential Applications Both near and far barcode scanning in same device for use in warehouse and distribution centers. Contactless technology and automation are transforming the way we live and work. Honeywell Logistics Sensing is developing the latest vision solutions to support a wide range of applications for: access control, retail, healthcare, transportation and logistics, warehouse and distribution, and hospitality. Specifications OTHERS Industry RetaiL
From a leading provider of OEM scanning solutions, the N4300 series offers high levels of performance and reliability for OEM customers and end users. The N4300 series achieves the highest reading accuracy among available laser scanning engines and can scan poor quality codes quickly and easily. And it's the only laser engine that includes built-in object detection for hands-free applications. Designed from the ground up with Honeywell's patented technologies, the N4300 series meets our strict quality standards. Unlike competing engines, the N4300 brings high performance scanning and unique capabilities to a wide range of applications, from mobile computers to scanners, kiosks and other self-service devices. The Smart Pick List mode improves targeting accuracy when scanning one barcode that's surrounded by other codes and the TTL model supports full duplex RS232 communication at a higher max baud rate, providing more flexibility and faster data communication than competitor products. The N4300 series delivers aggressive barcode scanning performance with a standard form factor and interface. Whether you're upgrading existing devices or adding a scanning solution to a new application, you'll find N4300 series engines easy to integrate, offering a durable, electrically grounded metal chassis and standard mounting hole locations. Features Compact and lightweight: Delivers a standard form factor and communication for easy integration, even in tight spaces Metal chassis: Provides durability with a grounded metal case, single board design, non-ZIF connector and shock protection up to 2,000 G Built-In object detection: Facilitates hands-free operation, eliminating the cost of adding external object detection on the host Advanced decoding technology: Offers lowest misread rate compared to competing laser engines: configurable decoding security levels eliminate costly reading errors on hard-to-read poor quality codes Smart Pick List: Program the device to read only bar codes found at the center, or any other location on the scan line, improving targeting accuracy SR and HD available: We provide both SR (standard range) and HD (high density) versions, to meet multiple applications with vertical focus Contactless technology and automation are transforming the way we live and work. Honeywell Logistics Sensing is developing the latest vision solutions to support a wide range of applications for: access control, retail, healthcare, transportation and logistics, warehouse and distribution, and hospitality. Specifications OTHERS Industry Retail
Designed for in-store retail environments requiring a highly accurate 2D scanning solution in a durable form factor, the Voyager™ Extreme Performance (XP) 1472g cordless scanner delivers reliable scanning capability on traditional barcodes and digital screens – even on damaged and difficult-to-read codes. The Voyager XP 1472g delivers precise decoding performance, even with poor and damaged barcodes, making it an ideal choice for workflows that involve 1D and 2D barcode reading and require a robust and reliable solution. The scanner’s extended scan distance will reach right to the bottom of the cart without bending and wasted time at the checkout. Engineered to 30 drops at 1.8 m (6 ft) and 1,000 tumbles at 0.5 m (1.6 ft), the Voyager XP 1472g scanner is built to work with low cost of repair or downtime even in a harsh environment. The Voyager XP 1472g offers 100m Bluetooth range under Bluetooth 4.2 mode for secure data transmission and premium workflow flexibility. Voyager XP 1472g provides full shift battery performance with up to 100,000 scans per charge. This enables workers to operate on-the-move and frees them from the need to frequently return the scanner to its base. Specifications FEATURES Connectivity Bluetooth Form Factor Gun Shape Application Point of Sale Retail Features Honeywell Scanner Management Utility (SMU) DIMENSIONS Overall Dimensions 2.4 x 6.8 x 3.2 in 6.2 x 17.3 x 8.2 cm SCANNING SPECIFICATIONS Skew 70 Decode Capability 1D/2D Motion Tolerance 70 cm/s (27.6 in/s) for 13 mil UPC at optimal focus Number of Scans 50000 Scanning Range Standard range (SR) Depth of Field 0.2 - 15.8 in Scan Distance Standard Range (0-1m) Scan Pattern Area Image Brightness 0 - 100000 lux Pitch 65 NETWORK Bluetooth Specifications v4.2 Bluetooth Yes HARDWARE Host System Interface KBW RS-232 USB Power Connector Type Cordless Aimer Type LED Wireless Yes Charging Contact Charging ELECTRICAL Battery Type Li-ion Battery ENVIRONMENTAL Minimum Operating Temperature 41 °F 5 °C Storage Temperature Range - 20 - 35 °C - 4 - 95 °F Operating Temperature 41 - 104 °F 5 - 40 °C Operating Humidity 0 - 95 % STANDARDS & APPROVALS Tumble Specifications 1,000 0.5 m (1.6 ft) tumbles Drop Specifications 30 1.8 m (6 ft) drops to concrete Protection Ratings IP52 IP Rating IP52 SERVICE TERMS Warranty Duration. 3 yr ERP Brand Honeywell OTHERS Industry Government & Public Sector Manufacturing Retail.
